Leak Detection in Fort Morgan, CO — Find It Before You Open a Wall
A water bill that jumped 30% with no change in usage. A ceiling stain that keeps reappearing after patches. A soft spot in the flooring with no visible source. These are signs of a hidden leak that's been running long enough to cause structural damage — and every day it runs is money lost and damage accumulating. Masters Plumbing Service uses acoustic ground microphones, thermal imaging cameras, and precision pressure testing in Fort Morgan, CO to locate leaks without speculative demolition.
4 Detection Capabilities We Bring to Every Leak Detection Call
No single detection method works for every leak scenario. Our technicians are trained on four distinct approaches and select the right tool — or combination of tools — based on the pipe type, building construction, and leak characteristics.
🎙️
Acoustic Ground Microphone
Acoustic detection is most effective on metal pipe (copper, cast iron) under slab or in concrete — materials that conduct sound efficiently. It works in quiet environments and requires shutting off the house briefly to establish a clean acoustic baseline.
🌡️
Infrared Thermal Camera
Active water leaks — hot or cold — create a temperature differential on the surfaces they contact. An infrared camera shows these differentials as color-coded heat maps, revealing the wet zone inside a wall or under a floor without any cutting. A cold water leak behind drywall appears as a spreading blue-gray cool zone; a hot water leak shows the inverse.
📉
Pressure Decay Testing
We isolate the supply system, pressurize it to operating pressure, and monitor pressure over a timed hold period. Any pressure drop confirms active water loss from the supply side. By isolating zones — hot side vs. cold side, section by section — we narrow down which branch of the supply system is leaking before the detection phase begins.
💨
Tracer Gas Detection
For leaks that don't produce sufficient acoustic signature — very slow leaks, polyethylene pipe, or leaks deep under concrete — we can introduce a nitrogen/hydrogen tracer gas mixture into the isolated pipe and use a calibrated gas detector at the surface to find where the gas escapes. The detection sensitivity can locate leaks that produce no discernible pressure drop during a standard timed test.
What We Locate
Leak Detection for Walls, Slabs, Pools & Irrigation in Fort Morgan
Our detection service covers the full property, not just the obvious locations.
Under Slab
Slab Leak Detection
Supply lines run under or through the concrete slab in most slab-on-grade homes. When these lines fail — from corrosion, shifting, or manufacturing defects — the leak is invisible from the surface but audible to acoustic equipment. We walk the floor on a grid pattern, map the loudest detection points, and triangulate to a specific floor location, typically within a square foot.
In-Wall
In-Wall & Ceiling Leak Detection
We document the thermal anomaly, mark the approximate pipe location, and recommend a minimal access cut rather than a wide wall opening.
Water Main
Underground Supply Line Detection
Supply lines between the meter and the structure run underground and are vulnerable to corrosion, ground movement, and tree root damage. A main supply line leak shows as unusually high meter usage with all interior fixtures off, sometimes with wet ground or sinkholes along the line path. Acoustic detection locates the failure in the buried line precisely enough to minimize excavation footprint.
Pool & Irrigation
Pool Line & Irrigation Leak Detection
Irrigation system leaks in main supply lines and lateral runs are found by isolating zones with the irrigation controller and pressure-testing each zone individually. Zone by zone testing narrows the failure to the smallest possible section.
Commercial
Commercial Property Leak Detection
Commercial water loss from undetected leaks often shows up as elevated utility bills for months before physical evidence appears. We can assess a commercial building's plumbing system for suspected leaks at the property owner's or property manager's request.
Documentation
Leak Detection Report for Insurance
We format detection reports specifically for insurance submission and can provide documentation on our detection equipment and methodology to claims adjusters on request.
How Our Leak Detection Process Works in Fort Morgan, CO
Here's exactly how a Masters Plumbing Service leak detection call plays out.
1
Initial Water Loss Confirmation
We start at the meter. All fixtures off, we watch the meter for 10 minutes. Movement confirms active water loss from the supply side. We also check for any visible evidence — water stains, soft floors, moisture readings with a moisture meter at suspect wall surfaces.
2
Zone Isolation & Pressure Decay
We isolate the supply system into zones — hot side, cold side, and if possible, individual branches — and pressure-test each zone to determine which branch is losing water. This narrows the area of active search significantly before detection equipment is deployed.
3
Detection Equipment Deployment
Within the isolated zone, we deploy thermal imaging first — scanning walls, floors, and ceilings for moisture anomalies. Then acoustic equipment confirms the specific pipe location and narrows it to the tightest possible point. Tracer gas is added if acoustic results aren't conclusive.
4
Written Report & Repair Options
Insurance claims: the report is formatted to support a claim for water damage from a concealed leak. We can provide supplemental documentation on request.
Customer Reviews
Fort Morgan, CO Homeowners Who Found Their Leak with Masters Plumbing Service
★★★★★
High-efficiency home with a leak that defied normal detection. Water loss was slow — about 1.5 gallons per hour. The tech used tracer gas after pressure testing confirmed the loss but acoustic detection couldn't localize it clearly. Gas detection found the escape at a micro-fitting under the slab in the utility corridor. Impressive work.
— C. Thornton, Fort Morgan
★★★★★
Our insurance company required professional leak detection documentation before approving the claim. Masters Plumbing Service's written report with pressure test data and thermal imagery was exactly what the adjuster needed. Claim approved. The detection cost was covered as part of the claim.
— B. Osei, Fort Morgan, CO
★★★★★
Commercial building where water costs were running 40% above baseline for six months. Masters Plumbing Service ran a systematic zone-by-zone pressure isolation across four floors, narrowed the loss to the third-floor kitchen supply branch, and located the failure with thermal imaging at a concealed valve body in the ceiling. No damage to the finished ceiling.
— T. Anand, Fort Morgan, CO
Common Questions
Leak Detection Questions We Answer in Fort Morgan
The most reliable self-check: shut off every fixture and appliance in the house, then watch the water meter for 15 minutes. Any movement — including the small leak indicator dial — means water is escaping the supply side somewhere. If the main meter dial moves with everything off, you have a leak. Call us to locate it.
The repair itself requires physical pipe access, which typically means a small, targeted opening. But that's a completely different proposition from opening large wall sections while searching for an unknown leak location.
For leaks in plastic pipe, low-pressure situations, or high-noise environments, accuracy may be lower and tracer gas becomes the preferred supplemental method.
We can provide supplemental information to claims adjusters on request, including equipment calibration records and a technical description of the detection methodology used.
A standard residential leak detection — confirming water loss, isolating the failing zone, and deploying detection equipment to locate the failure — typically takes 1.5–2.5 hours. More complex scenarios (multi-zone commercial, large properties, very slow leaks requiring tracer gas) can run 3–4 hours.
Yes — and for most residential leaks, we can repair the failure the same day detection confirms the location. Our service trucks carry the repair materials for the most common supply line failures. We quote the repair as a flat-rate job separate from the detection fee, and you decide whether to proceed with us or take the detection report to your own plumber.
Service Area
Leak Detection Available Across Fort Morgan, CO
Our detection technicians are equipped with acoustic, thermal, and tracer gas tools for the full range of leak scenarios found in Fort Morgan, CO homes and commercial properties.
Non-Invasive Leak Detection in Fort Morgan, CO — Book Your Appointment
Masters Plumbing Service's detection team finds hidden leaks in Fort Morgan homes and commercial properties using equipment that eliminates guesswork. The detection appointment pays for itself the moment it prevents one unnecessary wall opening.
